BioCeptor™ 470

Servicing Features

• Easy to operate
• Quick Job turnaround
• No messy cleanup or time-consuming cleaning processes

"The BioCeptor™ remains very clean and when it comes to servicing the matter build-up just slides off on lifting out the tube! It pretty much cleans itself"

Operational Features

• The unique design offers non-mechanical self-cleaning features
• Effective long-term filtering of particles
• High flow rates maintained between servicing intervals

"The segment screen size of the BioCeptor™ on the outer rim allows the collected matter to sloth off over time also keeping itself clean"

Design Features:

Construction:

316 Stainless Steel components. This creates a strong filter that survives performance in a tough environment and cleaning process.

Complimentary:

Fits inside industry-standard pipes

Compliance:

Designed to satisfy or exceed the requirements of the related building standards.

Invert:

The filter seats on the top ledge of a standard PVC Square Junction (TEE) fitting. This determines the dimension from the seat to the highest invert of the outlet pipe (typically 110mm).

Filtration:

The star configuration of the filter body is perforated with over 15,600 holes each measuring 3.0mm dia. maximum. (0.11m2)

Bioceptor 316-3-380 (over 15,600 holes)

Bioceptor 316-3-470 (under 15,600 holes)

Bioceptor 316-3-600 (under 15,600 holes)

Flow-through:

The interchange plate creates a separation between the filtration screen and the outlet screen.

The Interchange plate has a full through-opening of 57.7mm diameter.

Outlet screen:

The outlet screen has oval holes of 4.5x10.0mm These are larger than the screen to ensure unobstructed pass-through of the screened waste.

Cleaning:

The base of the Bioceptor Filter has a simple plate that unscrews from the main filter. This allows you to easily remove the base and flush the filter clean.

Options:

Cluster arrangements are available. These are typically 5 filter units in a single housing. Note: The invert configuration remains the same as for a single unit.

Filter Unit Dimensions

105mm diameter

850mm long

Toilet Unit Weight 1.15kgs

5 Year Warranty:

Our Bioceptor Filter is made from 316 stainless steel and is designed to withstand normal operational use in a wastewater system.

Each filter manufactured by Bioceptor NZ Limited, and the housing in the case of CLUSTER filter arrangements, are covered by our manufacturer's 5 5-YEAR LIMITED warranty against manufacturing defects and faults.
